Technical parameters

Product Description

Commodity name: Hydrogen Generator

We offer a wide range of alkaline electrolyzers, from 0.5 Nm³/h to 2000 Nm³/h, optimized for various hydrogen production applications.

We offer a wide range of alkaline electrolyzers, from 0.5 Nm³/h to 2000 Nm³/h, optimized for various hydrogen production applications. Two product lines are available:

E Series – Grid Power Hydrogen Generation

Applications: On-grid/off-grid hydrogen generation, peak-valley power hydrogen generation.
Features:

Economic: Low DC power consumption.
Safe: Long-term stable operation.
Efficiency: Rapid Cold start and Wide response.

Hydrogen Production Capacity (Nm³/h)	Model	Operating Pressure (MPa)	DC Power Consumption (kWh/Nm³)
2	HX1-2E	1.6/3.2	≤4.0
5	HX1-5E
10	HX1-10E
20	HX1-20E
30	HX1-30E
50	HX1-50E
80	HX1-80E	1.6
100	HX1-100E	1.6
200	HX1-200E	1.6	≤4.0
300	HX1-300E
400	HX1-400E
500	HX1-500E
800	HX1-800E
1000	HX1-1000E
1200	HX1-1200E

C Series – Renewable Energy Hydrogen Generation

Applications: Wind/solar off-grid hydrogen generation, off-grid hydrogen generation.
Features:

Economic: Low Procurement Cost.
Safe: High Current Density.
Efficiency: Rapid Cold start and Wide response.

Hydrogen Production Capacity (Nm³/h)	Model	Operating Pressure (MPa)	DC Power Consumption (kWh/Nm³)
2	HX1-2C	1.6/3.2	≤4.3
5	HX1-5C
10	HX1-10C
20	HX1-20C
30	HX1-30C
50	HX1-50C
80	HX1-80C	1.6
100	HX1-100C	1.6
200	HX1-200C	1.6	≤4.3
300	HX1-300C
400	HX1-400C
500	HX1-500C
800	HX1-800C
1000	HX1-1000C
1200	HX1-1200C
